|Product Number:||EK6131UK||Functions:||Table Motorized Rotation Socket|
|Usage:||High-tier Office, Conference Room||Material:||Aluminum Alloy Surface Panel + Plastic|
|Overturn Angle:||180 Degree||Panel Size:||324*110 Mm|
|Color:||Black / Silver||Rated Voltage:||110V ~ 240V AC|
conference table power socket,
hidden power socket
UK standard power plug for office room desk flip up power socket outlet EK6131UK
EK Series rotatable tabletop socket is mainly used in advanced office, hotel and home, training room, lecture room. Tabletop socket could be used with other installation surrounding together. When power with the desktop power socket, the indicator light is power on, product come to working station. Press the up/ down switch, all the multi-functional sockets could be rotate 180 degree to whatever position as needed. All configuration on desktop socket could be hidden under table if unused and would be rotating into the tabletop by automatically.
1. High quality 3mm panel thickness aluminum panel surface, not easy to bend
2. Aluminum alloy wired drawing top panel, elegant fashion, simple appearance not easy to grind flower
3. Anode oxidation process, anti-scratch, anti-dusty and anti-rust, upscale elegance
4. Anti-pinch function, when the tabletop socket is turning, if there is something come and stay on the connector, the socket will turn back to the last position.
5. Easy installation, just cut out a square hole and install the socket on the table directly.
6. Safety design, anti-electric shock when the connection panel hidden under table after used.
7. With 1.5 meter extension connection cables
8. Save more space,after using you can close it with the button on panel to keep it anti-dusty, and the table tiny.
9. With quiet synchronous motor, panel socket can be rotating automatically via switch control.
1. USB charger system can be support with different input voltage and output charging current
2. Cable length are available with different length to 1.0m ~ 5m
3. Cable connection plugs can be changed with different standard
4. Changeable combinations, modules can be customized as you need accordingly
5. Interconnection box length can be available with difference quantities modules
6. Sample order and customized made is available
7. OEM/ODM and logo request is available
8. With CE / ROSH / UL / SASO approved
This tabletop hidden rotatable power socket is widely used for the high-class chairman room table, high-tier office table, conference room table AV solution, hotel room and work training room.
|Functions||Tabletop hidden motorized rotation socket|
|Usage||High-tier office, conference room|
|Application||Residential / General-purpose|
|Configuration||1*UK power+2*usb charger+1*high dmi+1*network|
|Material||Aluminum alloy surface panel + plastic|
|Panel process||Aluminum alloy wired drawing + anode oxidation surface process|
|Overturn angle||180 degree|
|Color||Silver (black is available)|
|Panel size||324*110 mm|
|Panel thickness||3 mm|
|Cutout size||295*104 mm|
|Box size||291*100*103 mm|
|Cable length||1.5 m (Length is available)|
|Configuration||3* Universal power outlets|
|Power connection||Universal power plug|
|Rated voltage||110V ~ 240V AC|
|Rated current||10 ~ 13 Amp|
|Frequency||50 / 60 Hz|
|Operation Temperature||-20°C / + 50°C|
|G. Weight||2.2 kgs|
|Packing dimension||48*68*36 cm/ctn|
|Packing weight||18 kgs/ctn|
VGA / HDMI / USB date / USB charger / Audio / Video / RCA
Network / Telephone / Microphone / Cat6 / XLR
Universal plug / EU standard plug / UK standard plug
AU standard plug / US standard plug / SA standard plug
