Product Details:
|
| Product Size: | 265*130*73 Mm | Box Size: | 222*110*65 Mm |
|---|---|---|---|
| Panel Thickness: | 7 Mm | Color: | Black |
| Material: | Zinc Alloy | Corner: | Rectangle |
| Configuration: | RCA, USB , HDMI , VGA , Audio 3.5 , RJ45 | Power: | Universal Power |
| Application: | Conference Table | Warranty: | 1 Year |
| Highlight: | table top electrical outlets,desk pop up sockets |
||
Rectangular Conference Desktop Hidden Pop Up Power Plug with Bottom Connection Cables
Introduction:
Desktop power plug is a hidden equipment with media socket for all office furniture, it is special for audio video solution. Made with excellent zinc alloy material panel, available with silver, black matte, gold, white, wood color to meet different requires. Contain all media configuration, like power, network, telephone, HDMI, VGA, USB, 3.5Audio, Video, RCA, audio video, XRL, DVI. Before installed into the table, need to weld the power and other media cables. Easy to install on table. Just cut a hole on the table, but put our product into table, fix it by screws.
User could use the media configuration by press the product button, the media socket would be pop up to the topside automatically. After use, just press the product cover into table by hand. Widely used in office furniture for audio video solution in conference system.
Feature:
1, Normally install desktop power plug on office furnishes, like office desk, meeting table or other office worktop.
2, Hidden socket into table underside to keep desktop surface more neat, modern and save more space. To supply a fashion and modern environment for office and meeting room.
3, Just press the product button, the spring inside the socket box will pop all media socket with plat up to the tabletop, user could plug each connector directly. Just press the cover back to table underside if finished using.
4, Desktop power plug connected with 30cm length media cables with female connectors. So user no need weld the power plug and other media cables again. Just plug the female connector with extension cable as you need. What is more, there are fuse inside the socket box to keep all media connector is safe from big current.
5, Panel surface made of zinc alloy material with anode oxidation process, bottom case made of steel material, powdering with black color. Antioxidative and won't loose color.
6, Socket box assemble with power outlet, data, HDMI, VGA, USB, audio and video connectors. Each configuration could changed as required.
Parameter:
| Product name | Desktop Hidden Pop Up Socket |
| Model number | BD610-1S |
| Material | Zinc Alloy finished |
| Panel size | 265 * 130 mm |
| Case size | 222 * 109 * 65 mm |
| Cutout size | 224 * 110 mm |
| Corner | Rectangle |
| Button | Rectangular Press Botton |
| Color | Black |
| Power | 1 * Universal Power Plug |
| Security | 10 Amp 250 V Fuse |
| Configuration | 1* Audio R&L / 1* USB / 1* HDMI / 1* VGA / 1* Audio 3.5 |
| Connteed cables | 1* Audio R&L / 1* USB / 1* HDMI / 1* VGA / 1* Audio 3.5 |
| Cable Length | 30cm |
| Usage | Desktop socket |
| Certification | UL/CE/ROSH/SASO |
Drawing:
Application:
Desk hidden socket offer a hidden equipment for audio video solution in office furniture. Could save more space and keep table integral and conforming. To supply a fashion and modern environment for office and meeting room.
Product Pictures:
