Product Details:
|
Product: | LCD Monitor Lift | Style: | Monitor Lift With Touch Screen |
---|---|---|---|
Material: | Aluminum Drawing Finishing | Panel Size: | 630*110*5mm |
Thickness: | 5mm | Case Size: | 610*550*100mm |
Screen Size: | 21.5 Inch LED Touch Screen | Resolution: | 1920*1080 |
High Light: | motorized lift mechanism,hidden monitor lift |
with remote control 60 degree folding angle lcd monitor lift
Introduction:
Ultra-thin LCD Monitor Motorized Lift is ultra-thin hiding equipment designed with HD screen for audio video system in office furniture. The LED HD screen of monitor lifting system would be rising down into the desk and hidden under the office table when unused; Screen inside the LCD lift would be rising up from table automatically by touch switch or remote control and present the workable screen on the desktop if used. It's integrated with HD screen all in one lifting system.
Feature:
1, Supply with whole aluminum alloy brushed case for HD screen monitor, with aluminum wire drawing process on surface.
2, The Monitor Lift adopts synchronous orbit lifting principle.
3, Desktop Vertical Monitor Lift works smoothly and quietly. Low noise which less than 30db.
4, LCD Motorized Lift provides protecting function of LCD monitors by cutting the electricity off automatically.
5, LCD monitor Lift would be adjustable elevation angle of LCD monitor for protecting your eyes from the direct light.
5, Tabletop Monitor Lift is controlled by two big AC motors. One controls opening and closing the panel of LCD monitor Lift; one controls lifting the monitor up and down and adjust the angles of the monitor.
6, Control system: up/down/titl/back button, RF remote control, RS232 input & output, USB input & cable, HDMI input
Functionality
LCD motorized monitor lift with HD screen all ine one lifting system
Monitor inclinates automatically to a pre-adjusted angle
12V step monitor with simultaneous drive for multiple movements
Second motorization for tile mechansim
Supply with 15.6inch, 17.3inch,18.5inch full HD LED screen
Customized required with touch screen, all in one PC monitor, Microphone
Quality approved by CE & SASO
Application:
LCD Monitor Lift is widely used on conference system, like video conference system, tv conference system, financial analyzing system, advanced office system, lecture and training room with conference table& computer desk together.
Detail Parameter
BET | Model No. | BLL45-21.5 |
style | Ultra-thin LCD Monitor Lift | |
Material | Panel | aluminum brushed |
Frame | aluminum brushed | |
Cover | aluminum brushed | |
surface | tempered glass | |
Dimension | Panel | 550*73*4mm |
Panel with MIC | 700*73*4mm | |
Inner panel | 470*30mm | |
Box | 530*70*600mm | |
Monitor frame thickness | 13-14mm | |
Information | Pitch Angle | 12° / 15° / 30° |
Switch | up/down/stop | |
Selection | Color | silver/ black/ gold/titanium |
Switch | computer /central control | |
Panel Input | USB/HDMI | |
Monitor | Size | 18.5 LED screen |
Brand | Samsung | |
Format | 16: 9 | |
Resolution | 1366*1080 |
